        V series

V series:

V series: V series solenoid valve and pilot valve is the common controlling element, which has the full kinds of port size, from 1/8” to 1”. And It also has different specification, flow rate and position. It has many connecting ways with the execution element.

3V4V3A4A2V
4V210-08


3v
Joint Pipe Bore Air Inlet=Outlet=Exhaust=M5～PT1/2
Working Medium 40 Micron Filtered Air
Working-pressure 15～80KG/CM2
Max.Pressure Resistance 1.2Kgf/c㎡
Operating Temperature -5～60℃
Voltage Range ±10%
Insulation&Protection Class F Class.IP65
Highest Action Frequency 5 Cycle/Sea
Shortest Excitation Time 0.05 Second
3v Ordering Code.
10 06 NO AC110V
Coil and Places Joint Pipe Bore Initial State Standard Voltage
10:Single-head Double-position M5:M5 NC:Normal Close Type DC12V
20:Double-head Double-position 06:PT1/8 *NO:Normal Open Yype DC24V
  08:PT1/4   AC24V 50Hz/60Hz
  10:PT3/8   AC110V 50Hz/60Hz
  15:PT1/2   AC220V 50Hz/60Hz
      AC380V 50Hz/60Hz
